Memmert CO2 Incubators

Control technology

Control Technology:

• ControlCOCKPIT: TwinDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with 2 high-definition TFT-color displays
• Adjustable parameters: temperature (Celsius or Fahrenheit), CO2, program time, time zones, daylight savings time
• Function Setpoint WAIT: the process time does not start until the set temperature is reached
• Language setting: German, English, Spanish, French, Polish, Czech, Hungarian

Safety & Standards

Safety

• AutoSAFETY:
  additionally integrated over- and undertemperature protection "ASF", automatically following the setpoint value at a preset tolerance range, alarm in case of over- or undertemperature, heating function is switched off in case of overtemperature, cooling function in case of undertemperature
• Autodiagnostic system:
  for fault analysis
• Alarm:
  audible and visual


Additional data

Electrical data

115 Volts

• 50/60 Hz
• approx. 13.0 amps

230 Volts

• 50/60 Hz
• approx. 6.5 amps

Certifications

Interior & Exterior

Stainless Steel Interior:

• Dimensions w(A) x h(B) x d(C):  22” x 18.9” x 15.7” (d less 1.4” for fan)
• Interior: material 1.4301 (ASTM 304), corrosion resistant
• Volume: 107 l / 3.8 cu. Ft.
• Max. number of shelves: 6
• Max. loading of chamber: 198 lbs
• Max. loading per shelf: 33 lbs

Stainless Steel

For many years exterior textured stainless steel has been the unmistakable feature of Memmert ovens, incubators, and climate chambers in laboratory and light-industrial settings. Memmert equipment exemplifies functional design in its most elegant and hygienic form, while still being scratch resistant, robust and durable.

Stainless steel is the ideal material for temperature control chambers and heating baths. It is particularly corrosion-resistant, hygienic, robust and recyclable without question.

Wherever Memmert ovens and heating baths are used, the superiority of high-quality stainless steel is undeniable in comparison to others that utilize coated sheet steel, which can corrode very quickly when in constant use.

For the outer housing of all Memmert appliances, textured stainless steel is used (rear walls are zinc-plated sheets). The inner chamber, sliding shelves/grids, housing, interior basin and accessories for every heating bath, stainless steel of class W-St. 1.4301 (ASTM 304) is used. Since aggressive substances are frequently used in the vacuum drying oven, the inner chamber and thermoshelves are made of stainless-steel W-St. 1.4404 (ASTM 316L), and the tubing is made of stainless-steel W-St. 1.4571 (ASTM 316i).

Accessories



Model sizes	50	105	150	240
Perforated stainless steel shelf	E35160	E37418	E37418	E35158
Water dish	B38737	B38737	B38737	B38737
Central water supply with filter cartridges for connection to the domestic water supply, only in combination with option K7. Product information on demand	ZWVR6	ZWVR6	ZWVR6	ZWVR6
Central water supply, without filter cartridges for connection to the domestic water supply (only for demineralised water with a conductivity of 5 to 10 μS/cm and a pH value between 5 and 7) only in combination with option K7. Product information on demand	ZWVR7	ZWVR7	ZWVR7	ZWVR7
HEPA14-filter for chamber according to EN 1822, packed in sterile condition, incl. fixing unit	B49800	B49800	B49800	B49800
3 HEPA14-filters (B49800) for chamber according to EN 1822, packed in sterile condition, incl. fixing unit	B39698	B39698	B39698	B39698
Guarantee extension by 1 year	GA3Q5	GA3Q5	GA3Q5	GA3Q5
USB-Ethernet adapter	E06192	E06192	E06192	E06192
Ethernet connection cable 5 m for computer interface	E06189	E06189	E06189	E06189
USB User-ID stick (with User-ID licence): Oven-linked authorisation licence (User-ID-programme) on Memory-stick, prevents undesired manipulation by unauthorised third parties. When reordering please specify serial number (only for units with TwinDISPLAY)	B33170	B33170	B33170	B33170
Stacking set (4 pcs) for stacking of appliances of same size	B29744	B29744	-	-
Stacking set (consisting of stacking corners, one connecting plate for the rear, two wall brackets) for stacking of two units of same size (size 240 only in combination with subframe B33509 or B43598)	-	-	B42114	B48129
Subframe (622 mm high) adjustable in height (sizes 150/240: should not be used for 2 stacked units)	B33504	B33505	B33505	B33506
Subframe (130 mm high); sizes 150/240: only in combination with the corresponding stacking sets for stacked appliances	B33507	B33508	B33508	B33509
Subframe, on castors (height 120 mm; stainless steel, material 1.4301)	-	-	-	B43598
CO2 pressure reducing valve DIN 8546, incl. Gas cylinder monitor	E02087	E02087	E02087	E02087
N2 pressure reducing valve to DIN EN ISO 2503, incl. gas cylinder monitor (requires option T6)	E06162	E06162	E06162	E06162
Celltron benchtop shaker (not subject to discount) - accessories upon request (only in combination with E06726)	-	-	-	B43598
CO2 pressure reducing valve DIN 8546, incl. Gas cylinder monitor	E02087	E02087	E02087	E02087
N2 pressure reducing valve to DIN EN ISO 2503, incl. gas cylinder monitor (requires option T6)	E06162	E06162	E06162	E06162
Celltron benchtop shaker (not subject to discount) - accessories upon request (only in combination with E06726)	-	-	-	E06724
Base plate with sticky stuff (not subject to discount) (only in combination with E06724)	-	-	-	E06726
External measuring instrument with additional measuring head for temperature and humidity measurement. Product information on demand	B04714	B04714	B04714	B04714
IQ/OQ document with device-specific works test data for one free selectable CO2 and temperature value, incl. temperature distribution survey at Memmert for 27 measuring points to DIN 12880:2007-05, PQ check list as support for validation by customer	D38898	D38898	D38898	D38898
IQ/OQ document with device-specific works test data for one free-selectable CO2, humidity and temperature value, incl. temperature distribution survey at Memmert for 27 measuring points to DIN 12880:2007-05, PQ check list as support for validation by customer (requires option K7). Price for further CO2, humidity and temperature values on demand	D38897	D38897	D38897	D38897
Software conforming to FDA AtmoCONTROL. Meets the requirements for the use of electronically stored data sets and electronic signatures as laid down in Regulation 21 CFR Part 11 of the US Food and Drug Administration (FDA). Base licence for reading the data logging of one unit (only for units with TwinDISPLAY). Respective IQ/OQ documents available in German and English language (without surcharge)	FDAQ1	FDAQ1	FDAQ1	FDAQ1
Integration of one additional unit (up to max. 31 units) into an already existent FDA-software licence (only for units with TwinDISPLAY)	FDAQ2	FDAQ2	FDAQ2	FDAQ2
DAkkS calibration for one (freely selectable) temperature and humidity value according to method C (DKD-R 5-7) (requires option K7)	E48847	E48847	E48847	E48847
DAkkS calibration for further temperature and humidity values according to method C (DKD-R 5-7) (requires option K7)	E48848	E48848	E48848	E48848
IQ document with device-specific works test data, OQ/PQ check list as support for validation by customer	D00124	D00124	D00124	D00124
On-site IQ/OQ for a freely selectable temperature and CO2 value, including temperature distribution survey for 27 measuring points to DIN 12880: 2007-05 (excluding travel costs, not subject to discount, GER, AT, FR only)	DLQ102	DLQ102	DLQ102	DLQ102
Extension of DLQ102 by an additional freely selectable temperature and CO2 value (not subject to discount)	DLQ102A	DLQ102A	DLQ102A	DLQ102A
On-site IQ/OQ for a freely selectable temperature, humidity and CO2 value, including temperature distribution survey for 27 measuring points to DIN 12880: 2007-05 (requires option K7) (excluding travel costs, not subject to discount, GER, AT, FR only)	DLQ103	DLQ103	DLQ103	DLQ103
Extension of DLQ103 by an additional freely selectable temperature, humidity and CO2 value (requires option K7) (not subject to discount)	DLQ103A	DLQ103A	DLQ103A	DLQ103A
On-site IQ/OQ for a freely selectable temperature, CO2 and O2 value, including temperature distribution survey for 27 measuring points to DIN 12880:2007-05 (requires option T6) (excluding travel costs, not subject to discount, GER, AT, FR only)	DLQ104	DLQ104	DLQ104	DLQ104
Extension of DLQ104 by an additional freely selectable temperature, CO2 and O2 value (requires option T6) (not subject to discount)	DLQ104A	DLQ104A	DLQ104A	DLQ104A
On-site IQ/OQ for a freely selectable temperature, humidity, CO2 and O2 value, including temperature distribution survey for 27 measuring points to DIN 12880: 2007-05 (requires option K7 and T6) (excluding travel costs, not subject to discount, GER, AT, FR only)	DLQ105	DLQ105	DLQ105	DLQ105
Extension of DLQ105 by an additional freely selectable temperature, humidity, CO2 and O2 value (requires option K7 and T6) (not subject to discount)	DLQ105A	DLQ105A	DLQ105A	DLQ105A
Individual on-site Performance Qualification (PQ)	DLQ200	DLQ200	DLQ200	DLQ200
Maintenance ICO/ ICOmed passive humidity - carrying out and documentation according to Memmert maintenance plan (excluding travel costs, not subject to discount, GER, AT, FR only)	S00323	S00323	S00323	S00323
Maintenance contract ICO/ ICOmed passive humidity - carrying out and documentation according to Memmert maintenance plan, minimum duration 3 years (excluding travel costs, not subject to discount, GER, AT, FR only)	S00323J	S00323J	S00323J	S00323J
Maintenance ICO/ ICOmed active humidity - carrying out and documentation according to Memmert maintenance plan (requires option K7) (excluding travel costs, not subject to discount, GER, AT, FR only)	S00312	S00312	S00312	S00312
Maintenance contract ICO/ ICOmed active humidity - carrying out and documentation according to Memmert maintenance plan, minimum duration 3 years (requires option K7) (excluding travel costs, not subject to discount, GER, AT, FR only)	S00312J	S00312J	S00312J	S00312J
Calibration of one freely selectable temperature value (excluding travel costs, not subject to discount, GER, AT, FR only)	S00205	S00205	S00205	S00205
Calibration of an additional temperature value (not subject to discount)	S00215	S00215	S00215	S00215
Calibration of one freely selectable temperature and humidity value (requires Option K7) (excluding travel costs, not subject to discount, GER, AT, FR only)	S00207	S00207	S00207	S00207
Calibration of an additional temperature and humidity value (requires option K7) (not subject to discount)	S00216	S00216	S00216	S00216
Calibration of one freely selectable temperature and humidity value including CO2 (excluding travel costs, not subject to discount, GER, AT, FR only)	S00211	S00211	S00211	S00211
Calibration of an additional temperature and humidity value including CO2 (not subject to discount)	S00217	S00217	S00217	S00217
